Network-capable, fanless compact measurement systems

Why settle for anything less than state of the art? All-purpose, network-capable, real-time measurement devices with built-in measurement amplifiers and easy-to-use, ready-to-go user interface software are now available in a compact package: The imc C-SERIES...

Universal data acquisition device for development, testing and service

The imc C-SERIES consists of smart network-capable, unventilated compact data acquisition devices for all-purpose measurement of physical quantities. These devices can operate either in computer-aided or autonomous mode and are lightweight, compact, and robust, thus, especially well adapted to applications in R&D or in the testing of mechanical and electromechanical components of machines, on board vehicles, or in monitoring tasks in installations.

At a glance

  • Cost effective, ready-to-go system
  • Universal approach covers broadest range
  • Most portable imc data acquisition system
  • Simultaneous recording of analog, digital, and CAN/vehicle bus data (including fast CAN FD)
  • Up to 400 kS/s per system and up to 100 kS/s per channel
  • Universal signal conditioner
  • Sophisticated and intuitive triggering system
  • Versatile storage options including onboard removable flash media
  • Networkable with other imc systems for synchronous acquisition of thousands of channels
  • Integrated real-time analysis and data reduction
  • Standalone, remote or interactive operation (via Ethernet TCP/IP connection)
  • Configuration and operation software: imc STUDIO
  • For comprehensive data analysis and reports, imc FAMOS software is ideal
